Model : HM-704
Item Code No. : 156-0002
Counting Range : 99999.99 hr.
Square Front : 52 mm x 52 mm
Rated Voltage : 220V, 50Hz
Consumption : 2 Watt
H.V. Test : 2 KV for 1 minute
Temperature Range : -20 oooo C to 65 oooo CCCC
Figures: White on black for full hours
: Red on white for fractional hours
Accuracy of Display : 1/100th
Weight : 55 gms. approx.
Mounting : Flush panel mount with plastic mounting clamp
CDG31
GE CDG31 TP Normal Inverse IDMT O/C Relay in drawout case 3DH, 5A with setting of 50-200% (2.5-10A) and a tripping time of 1.3 sec. at 10 times of setting current
CDG34
GE CDG34 TP Extermely Inverse IDMT O/C Relay in drawout case 3DH, 5A with setting of 50-200% (2.5-10A) and a tripping time of 0.63 sec. at 10 times of setting current
