Electronic Timer Relay (JSZ8-C) Source: 220V AC 50/60Hz : Contact: 3A 250V AC Resistive Load
Order Now
GE CDG11 SP Normal Inverse IDMT E/F Relay in drawout case D, 5A with setting of 10-40% (0.5-2.0A) and a tripping time of 1.3 sec. at 10 times of setting current
Ablewise AVM25 ordering code D-5A-P1-32MB, advanced power and energy analyser with LCD display for 690V/5A 3 phase AC input, 4th CT for measuring neutral current, THD and individual harmonics up to 63rd order, 32MB onboard memory of which 16MB is reserved for data logging, auxiliary voltage 100-415V single phase AC or 100-300V DC.
Ablewise AVM25 ordering code D-5A-P2-32MB, advanced power and energy analyser with LCD display for 690V/5A 3 phase AC input, 4th CT for measuring neutral current, THD and individual harmonics up to 63rd order, 32MB onboard memory of which 16MB is reserved for data logging, auxiliary voltage 20-60V DC
Ablewise AVM2-IP66 front protection cover
Ablewise AVM2-IO1 module, 6DI, 2RO, 1 pulse output
Ablewise AVM2-IO2 module, 4DI, 2RO, 2 analog output
Ablewise AVM2-IO3 module, 4DI, 2RO, 2 analog output
(Any 2 of the above 3 IO modules can be added to the same meter)
Ablewise AVM2-TM0, 5 channel temperature module with 2.5m long cable and sensor, 2RO
Ablewise AVM2-TM8, 5 channel temperature module with 2.5m long cable and sensor for M8 screw fixing, 2RO
Ablewise AVM2-TM10, 5 channel temperature module with 2.5m long cable and sensor for M10 screw fixing, 2RO
Ablewise AVM2-TM12, 5 channel temperature module with 2.5m long cable and sensor for M12 screw fixing, 2RO
Ablewise AVM2-RT multi point wireless temperature module
Ablewise AVM2-SRT multi point wireless temperature sensor
Ablewise AVM3, ordering code 5A-P1, power and energy quality monitoring meter, with 3.5″ colour LCD display, auxiliary voltage 100-415V AC or 100-300V DC.
Ablewise AVM3, ordering code 5A-P2, power and energy quality monitoring meter, with 3.5″ colour LCD display, auxiliary voltage 20-60V DC.
Ablewise AVM3 Plus, ordering code 5A-P1, power and energy quality monitoring meter, with 5″ colour LCD display, auxiliary voltage 100-415V AC or 100-300V DC.
Ablewise AVM3 Plus, ordering code 5A-P2, power and energy quality monitoring meter, with 5″ colour LCD display, auxiliary voltage 20-60V DC.
Ablewise AVM3-101 add-on module for AVM3 and AVM3 Plus, 2RO+6DI.
CDG31
GE CDG31 TP Normal Inverse IDMT O/C Relay in drawout case 3DH, 5A with setting of 50-200% (2.5-10A) and a tripping time of 1.3 sec. at 10 times of setting current
CDG34
GE CDG34 TP Extermely Inverse IDMT O/C Relay in drawout case 3DH, 5A with setting of 50-200% (2.5-10A) and a tripping time of 0.63 sec. at 10 times of setting current
Model : HM-704
Item Code No. : 156-0002
Counting Range : 99999.99 hr.
Square Front : 52 mm x 52 mm
Rated Voltage : 220V, 50Hz
Consumption : 2 Watt
H.V. Test : 2 KV for 1 minute
Temperature Range : -20 oooo C to 65 oooo CCCC
Figures: White on black for full hours
: Red on white for fractional hours
Accuracy of Display : 1/100th
Weight : 55 gms. approx.
Mounting : Flush panel mount with plastic mounting clamp
