CDG31

GE CDG31 TP Normal Inverse IDMT O/C Relay in drawout case 3DH, 5A with setting of 50-200% (2.5-10A) and a tripping time of 1.3 sec. at 10 times of setting current

CDG34

GE CDG34 TP Extermely Inverse IDMT O/C Relay in drawout case 3DH, 5A with setting of 50-200% (2.5-10A) and a tripping time of 0.63 sec. at 10 times of setting current

Model : HM-704

Item Code No. : 156-0002

Counting Range : 99999.99 hr.

Square Front : 52 mm x 52 mm

Rated Voltage : 220V, 50Hz

Consumption : 2 Watt

H.V. Test : 2 KV for 1 minute

Temperature Range : -20 oooo C to 65 oooo CCCC

Figures: White on black for full hours

     : Red on white for fractional hours

Accuracy of Display : 1/100th

Weight : 55 gms. approx.

Mounting : Flush panel mount with plastic mounting clamp
